Hwm2424U20Bk 24U 24W 25.7D Swing Out Wall Cabinet w/ Vented Door

Hwm2424U20Bk 24U 24W 25.7D Swing Out Wall Cabinet w/ Vented Door

SKU: HWM2424U20BK | by Hammond Manufacturing
$1,283.57
Rackmount Solutions

Hwm2424U20Bk 24U 24W 25.7D Swing Out Wall Cabinet w/ Vented Door

SKU: HWM2424U20BK | by Hammond Manufacturing
$1,283.57
Shipping Method:
* Estimated Ship Date:

* Some exclusions apply. For an up to date shipping estimate contact sales@rackmountsolutions.net

Need help? Talk directly to our experts! 1-800-352-6631

Norton Secured

Product Information

24U 24W 25.7D Swing Out Wall Cabinet w/ Vented Door
  • Available in two (2) depths and four (4) heights.
  • All sizes include either vented 63% perforated front door or smoked window front door.
  • Includes one (1) pair of 10-32 threaded rack rails with support for additional optional rails (see accessory table).
    • Starter pack ofscrews.
  • Center section features:
    • Heavy-duty spring-hinge pin for easy installation and removal.
    • Sides that include two (2) vents and a fan grill.
    • Can be installed to swing from left-to-right or right-to-left.
  • Rear section features:
    • The side of the rear section includes 2.50” and 2.00” knockouts.
    • The top and bottom of the rear section include 3.00", 2.00”, 1.38” and 1.12” knockouts.
    • Generous cable management lances are located on the rear section as well as on mounting rails.
    • Mounting points for outlet strips.
    • Heavy-duty keyhole for wall mounting.
    • Large opening in the rear for cable access.
  • The front locking door and center section keyed the same (optional key available).

  • 14-gauge welded rear section; 16-gauge center section and doors.
  • EIA compliant adjustable depth mounting rails.
  • Grounding lugs located on top and bottom of the door, center and rear sections.
  • UL Listed 2416 load rated for up to 350 lbs (158 kg). Static Load tested to 1,400 lbs (635 kg).
  • Rugged sand-textured black powder paint reduces the look of fingerprints and marks.
  • TAA compliant for GSA Schedule purchases.
  • RoHS Compliant.
  • Manufactured in North America within an ISO 9001:2015 certified facility.
USMCA Compliant: Yes
REACH Compliant: Yes
Standards: culus, pci, taa-compliant
